The DspGraphDispatcher class manages the processing graph for the audio engine. More...

#include <src/engine/session/graph_dispatcher.h>

Collaboration diagram for zrythm::engine::session::DspGraphDispatcher:

[legend]

Public Member Functions
	DspGraphDispatcher (device_io::AudioEngine *engine=nullptr)
void	recalc_graph (bool soft)
	Recalculates the process acyclic directed graph.
void	start_cycle (const dsp::ITransport &current_transport_state, EngineProcessTimeInfo time_nfo, nframes_t remaining_latency_preroll, bool realtime_context) noexcept
	Starts a new cycle.
nframes_t	get_max_route_playback_latency ()
	Returns the max playback latency of the trigger nodes.
bool	is_processing_kickoff_thread () const
	Returns whether this is the thread that kicks off processing (thread that calls router_start_cycle()).
bool	is_processing_thread () const
	Returns if the current thread is a processing thread.

Data Fields
std::unique_ptr< dsp::graph::GraphScheduler >	scheduler_
std::atomic< bool >	graph_setup_in_progress_ = false
	An atomic variable to check if the graph is currently being setup (so that we can avoid accessing buffers changed by this).
EngineProcessTimeInfo	time_nfo_
	Time info for this processing cycle.
nframes_t	max_route_playback_latency_ = 0
	Stored for the currently processing cycle.
nframes_t	global_offset_ = 0
	Current global latency offset (max latency of all routes - remaining latency from engine).
std::atomic< bool >	graph_access_locked_ { false }
	Used when recalculating the graph - atomic flag for real-time safety.
std::atomic_bool	callback_in_progress_ = false
unsigned int	process_kickoff_thread_ = 0
	ID of the thread that calls kicks off the cycle.
device_io::AudioEngine *	audio_engine_ {}

Detailed Description

The DspGraphDispatcher class manages the processing graph for the audio engine.

The DspGraphDispatcher class is responsible for maintaining the active processing graph, handling graph setup and recalculation, and managing the processing cycle. It provides methods for starting a new processing cycle, retrieving the maximum playback latency, and checking the current processing thread.

Definition at line 51 of file graph_dispatcher.h.

Member Function Documentation

◆ is_processing_kickoff_thread()

bool zrythm::engine::session::DspGraphDispatcher::is_processing_kickoff_thread ( ) const

inlinenodiscard

Returns whether this is the thread that kicks off processing (thread that calls router_start_cycle()).

Definition at line 86 of file graph_dispatcher.h.

◆ is_processing_thread()

bool zrythm::engine::session::DspGraphDispatcher::is_processing_thread ( ) const

inlinenodiscard

Returns if the current thread is a processing thread.

Definition at line 94 of file graph_dispatcher.h.

◆ recalc_graph()

void zrythm::engine::session::DspGraphDispatcher::recalc_graph ( bool soft )

Recalculates the process acyclic directed graph.

Parameters

soft	If true, only readjusts latencies.

◆ start_cycle()

void zrythm::engine::session::DspGraphDispatcher::start_cycle	(	const dsp::ITransport &	current_transport_state,
		EngineProcessTimeInfo	time_nfo,
		nframes_t	remaining_latency_preroll,
		bool	realtime_context )

noexcept

Starts a new cycle.

Parameters

realtime_context	Whether this is called in a realtime context.
remaining_latency_preroll	Remaining number of playback latency preroll samples for this cycle.

Field Documentation

◆ audio_engine_

device_io::AudioEngine* zrythm::engine::session::DspGraphDispatcher::audio_engine_ {}

Definition at line 199 of file graph_dispatcher.h.

◆ callback_in_progress_

std::atomic_bool zrythm::engine::session::DspGraphDispatcher::callback_in_progress_ = false

Definition at line 194 of file graph_dispatcher.h.

◆ global_offset_

nframes_t zrythm::engine::session::DspGraphDispatcher::global_offset_ = 0

Current global latency offset (max latency of all routes - remaining latency from engine).

Definition at line 189 of file graph_dispatcher.h.

◆ graph_access_locked_

std::atomic<bool> zrythm::engine::session::DspGraphDispatcher::graph_access_locked_ { false }

Used when recalculating the graph - atomic flag for real-time safety.

Definition at line 192 of file graph_dispatcher.h.

◆ graph_setup_in_progress_

std::atomic<bool> zrythm::engine::session::DspGraphDispatcher::graph_setup_in_progress_ = false

An atomic variable to check if the graph is currently being setup (so that we can avoid accessing buffers changed by this).

Definition at line 178 of file graph_dispatcher.h.

◆ max_route_playback_latency_

nframes_t zrythm::engine::session::DspGraphDispatcher::max_route_playback_latency_ = 0

Stored for the currently processing cycle.

Definition at line 184 of file graph_dispatcher.h.

◆ process_kickoff_thread_

unsigned int zrythm::engine::session::DspGraphDispatcher::process_kickoff_thread_ = 0

ID of the thread that calls kicks off the cycle.

Definition at line 197 of file graph_dispatcher.h.

◆ scheduler_

std::unique_ptr<dsp::graph::GraphScheduler> zrythm::engine::session::DspGraphDispatcher::scheduler_

Definition at line 174 of file graph_dispatcher.h.

◆ time_nfo_

EngineProcessTimeInfo zrythm::engine::session::DspGraphDispatcher::time_nfo_

Time info for this processing cycle.

Definition at line 181 of file graph_dispatcher.h.

The documentation for this class was generated from the following file:

src/engine/session/graph_dispatcher.h
